16 PORT POE Switch : DS-3E0318P-E/M(B)

16-Port 10/100M PoE Switch with 1 Gigabit RJ45 + 1 Gigabit SFP Uplink | 130W PoE Budget | Long-Distance Support

Product Overview:

This L2 Unmanaged 16-Port PoE Switch is purpose-built for medium to large surveillance and network deployments. It features 16 PoE ports, 1 Gigabit RJ45 uplink, and 1 Gigabit SFP uplink port, offering flexible and high-speed uplink options. Compliant with IEEE 802.3af/at standards, it delivers a 130W total PoE power budget, with ports 9–16 supporting up to 300m long-distance transmission. Integrated 6KV surge protection ensures reliable performance in harsh environments.

Key Features:

• Ports:

  • 16 × 10/100M RJ45 PoE ports (IEEE 802.3af/at compliant)

  • 1 × Gigabit RJ45 uplink port

  • 1 × Gigabit SFP uplink port for fiber or long-distance backbone connections

• PoE Output:

  • Total PoE power budget: 130W

  • Supports IP cameras, wireless access points, VoIP phones, and other PoE-enabled devices

  • Ports 9–16 support up to 300 meters transmission distance in extended mode

• Uplink Options:

  • Dual uplink ports for flexible deployment: use copper for short-distance, SFP for fiber/long-distance

• Protection:

  • 6KV surge protection on all ports for improved durability in unstable power environments

• Switch Type:

  • L2 Unmanaged – No configuration needed, plug-and-play operation

Ideal For:

• Medium-to-large scale IP surveillance systems

• Business networks requiring flexible uplink (copper + fiber)

• Multi-floor or building-to-building deployments

• Long-distance PoE applications
